▒ 제품구성물

• 광 컨버터 본체 1개
• 아답터 1개
• 설명서

     * 본 제품은 SC멀티타입의 광 컨버터 입니다.

  ▒ 제품특징

• Fast Ethernet Compact Media Converter :
  10/100Base-TX to 100Base-FX Ethernet Media Converter


• Duplex/WDM Media Converter :
  Includes SC Duplex Transceiver or 1310/1550nm
  WDM Bi-directiona
  Transceiver(WBR)


• Optical Source :
  1310nm FP or 1550nm FP/DFB Source for SMF, 1310nm LED
  source for MMF(Max. 2Km), 850nm VCSEL Source for
  MMF/POF(Max. 2km)


• Manual or Auto-Negotiation : 10/100Base-TX, Auto-MDIX,
  Full duplex/Half duplex flow control (Manual operation by
  DIP switch)


• Standard :
  IEEE 802.3u 100Base-TX, 100Base-FX and IEEE 802.3
  10Base-T, 10Base-FL


• Flow Control :
  IEEE802.3x Flow control back pressure in half duplex


• Plastic Housing : w/EMI protection


• Diagnostic LEDs : TX, FX, PWR


• Power Adapter : A subminiature external AC/DC adapter
